Petzl RollClip A

The Rollclip A is a pulley-carabiner with a gate opening on the pulley side that facilitates installation of the rope when the pulley is fixed to the anchor. It is available with an automatic TRIACT-LOCK locking system, or without a locking system.

Features

• Easier handling: - sheave mounted on sealed ball bearings for excellent efficiency - gate opening on the pulley side facilitates installation of the rope when the pulley is fixed to the anchor - may be used with a CAPTIV positioning bar to favour loading of the carabiner along the major axis and to limit the risk of it flipping - Keylock system prevents any accidental snagging of the carabiner when putting the pulley in place
• H profile of carabiner: - ensures an improved strength-to-weight ratio - protects markings from abrasion
• Available in versions with or without TRIACT-LOCK locking system
• Non-Locking is a spring gate action
• Triact Lock is a 3 way locking system

Specifications

• Material(s): aluminium
• Min. rope diameter: 7 mm
• Max. rope diameter: 13 mm
• Sheave diameter: 18 mm
• Maximum working load: 2 x 2 = 4 kN
• Efficiency: 85 %
• Major axis strength: 20 kN
• Minor axis strength: 8 kN
• Open gate strength: 7 kN
• CE EN 362, EN 12275, EN 12278, UKCA, EAC
